Multifunctional Dual Head Terminal Crimping & Single Head Tinning Machine
The Multifunctional Dual Head Terminal Crimping and Tinning Machine is a high-efficiency wire processing solution designed for modern wire harness manufacturing. It integrates dual-head terminal crimping and single-head tinning into one compact system, significantly improving production speed and process flexibility.
With a production capacity of up to 5000 pieces per hour, this machine is ideal for high-volume electronic wire and flat cable processing. It is widely used in electronics manufacturing, electrical assembly, and industrial cable harness production lines.
Key Features
- ✔ Dual-head terminal crimping + single-head tinning integrated design
- ✔ High-speed production up to 5000 pcs/hour (5-wire batch basis)
- ✔ Supports 16–32# electronic wires and 2P–20P flat cables
- ✔ Adjustable cutting length from 35–1000mm
- ✔ Stable 2T crimping pressure for consistent quality
- ✔ Kinco HMI touchscreen for intuitive operation
- ✔ Compact structure suitable for production line integration
- ✔ Flexible processing for different wire specifications
- ✔ High reliability servo-driven components
- ✔ Industrial-grade continuous operation capability
Applications
This machine is designed for high-efficiency wire harness production environments requiring both crimping and tinning processes.
- Electronic wire harness manufacturing
- Automotive wiring assembly
- Electrical appliance production
- Industrial control systems
- Communication cable assembly
- Flat cable processing lines
Technical Specifications
| Item | Specification |
|---|---|
| Servo System | Leadshine / Yenko |
| Cylinder | Xingchen |
| HMI | Kinco Touch Screen |
| Control System | Single-chip Control |
| Solenoid Valve | YSC |
| Sensor | Omron Fiber Optic Sensor |
| Linear Guide | Taiwan Gaoji |
| Ball Screw | Taiwan Gaoji |
| Crimping Capacity | 5000 pcs/hour (5-wire batch basis) |
| Wire Range | 16–32# electronic wire |
| Flat Cable Range | 2P–20P |
| Cutting Length | 35–1000mm |
| Terminal Pressure | 2T |
| Tinning Depth | 13mm |
| Voltage | 220V |
| Air Pressure | 5KG |
| Weight | 450KG |
| Dimensions | 1880 × 1000 × 1550 mm |
Why Choose This Dual Function Machine?
This equipment combines two essential processes—terminal crimping and tinning—into one system, reducing equipment cost and saving production space. It is designed for manufacturers seeking higher efficiency and consistent output quality.
The synchronized dual-head structure ensures stable performance, while the single-head tinning system provides precise solder processing for improved electrical conductivity.
Flexible & High-Speed Production
With adjustable cutting lengths from 35mm to 1000mm and support for multiple wire types, this machine adapts easily to different production requirements. Its 2T crimping force ensures strong and reliable terminal connections.
The system is ideal for large-scale production environments requiring both speed and precision.
Request a Free Quote
Contact us today for pricing, customization options, and technical consultation for your wire harness production line.
Frequently Asked Questions
What is the production capacity?
Up to 5000 pieces per hour based on 5-wire batch processing.
What wire types are supported?
16–32# electronic wires and 2P–20P flat cables.
Is the machine suitable for continuous production?
Yes, it is designed for stable industrial continuous operation.
What is the cutting length range?
Adjustable from 35mm to 1000mm.
What is the crimping force?
2T stable crimping pressure ensures consistent quality.
